Cut To Length Line

TYPE:

QDH-H25-CL    QDH-E25-CL    QDH-25-CL

1 Machine design depends on different thickness and width.

2 Different hydraulic decoiler for optional (coils capacity, feeding trolley, press arm and support arm).

3 Whole line speed 50-60m/min.

Slitting Line

TYPE:

QDH-S25_SL    QDH-E25-SL    QDH-H25-SL

1 Machine design depends on different thickness and width.

2 Different hydraulic decoiler for optional (coils capacity, feeding trolley, press arm and support arm).

3 Optional AC motor or DC motor.

4 Whole line speed 150m/min.

5 Rectify device ensures material straightness.

Simple Slitting Line

TYPE:

QDH-S25-Sl

His unit is specially for round steel coil, which is divided into several strips by disc blade, and then rolled into required strip by equipment.

1 Cold rolled sheet, galvanized sheet.

2 The thickness ：0.5mm-2.0mm, max width:800mm

3 The number of blade:2-10 pcs, and the available length of shear shaft is 750mm

4 OD of decoiler : 2000m

5 ID of decoiler 508mm

6 Capacity of decoiler: 10Ton
